EPS Vacuum Shape Moulding Polystyrene Styrofoam Fish Boxes Making Machine has many improvements compare to the basic type shape molding machine and the features are as follows:
- Machine structure:
A, All frame are welded by 16/20mm steel plate with high machine legs, greatly improve machines’ stronger;
B, High machine legs made by strong “H” type profile. Which is easy for operator to collect products;
- Filling system: Adopt normal pressure\vacuum and high pressurized filling, hopper controlled by level sensor with double rotation chamber discharge, and 44 filling outlet;
- Steam system: Adopt balance PID control valve with Germany gauge, greatly improve accurate steam, and reduced consumption;
- Cooling system: Big vacuum pump with vertical tank, equip with vertical vacuum cooling water spray on the top, steam outlet has air\water separator, all these keep very high efficiency;
- Drainage system: Increased large inlet and outlet of mould, adopts 8- 1″ outlet for steam, keep fast cycle time, 8-2″ outlet for drainage system, keep fast drainage; And 6″ big drainage pipe controlled by butterfly valve, greatly increased fast steam and fast drainage operation;
- Control system:
A, Adopts PLC(Japan Mitsubishi) and touch screen (French Schneider) with easily operation;
B, All electronic components adopts famous brand(Schneider, Omron, Germany gauge), greatly increased stable;
C, The air cooling\steam\de-mould\pressure of filling controlled by long-distance adjustable and balance valve control.
Specifications:
| Model | Unit | LD-FB1220 | LD-FB1420 | LD-FB1620 | LD-FB1820 | LD-FB2000 |
| Mould size | mm | 1200*1100 | 1400*1300 | 1600*1500 | 1800*1700 | 2000*1900 |
| Product size | mm | 1050x850x350 | 1220x1100x350 | 1420x1300x350 | 1610x1400x350 | 1850x1650x350 |
| Max Mold Opening | mm | 1200 | 1400 | 1400 | 1400 | 1400 |
| Steam inlet | mm | 65 | 65 | 65 | 65 | 65 |
| Air inlet | mm | 80 | 80 | 80 | 80 | 80 |
| Steam pressure | Mpa | 0.5-0.7 | 0.5-0.7 | 0.5-0.7 | 0.5-0.7 | 0.5-0.7 |
| Air pressure | Mpa | ≥0.5 | ≥0.5 | ≥0.5 | ≥0.5 | ≥0.5 |
| External size | mm | 3600×1700×3000 | 4600×2000×3100 | 4600×2200×3200 | 4600×2400×3400 | 5000*2600*3600 |
| Weight | kg | 4300 | 4800 | 5200 | 6200 | 6500 |
